NZXT H1 Version 2 With PSU, AIO, And Riser Card (M-ITX) Mini Tower Cabinet (Matte Black)
Features:
The H1 allows you to get the most out of a small package. Pre-routed cables, a 750W PSU, support for the latest GPUs, and PCIe Gen 4 make the build powerful and simple.
- 140mm AIO liquid cooling
- NZXT CAM enabled fan controller
- SFX 750W Gold PSU included
- Chassis size accommodates latest NVIDIA 30 series & AMD 6000 series graphics cards
- Pre-routed cables and downward-facing motherboard I/O for a clean, simplified appearance.
- PCIe 4.0 Extender supporting maximum 25Gbps high-speed transmission
Specification:
| Key Specs | |
| Motherboard Support | Mini-ITX |
| Case Material | SGCC Steel, Tempered Glass |
| Dimensions | |
| Height | 405 mm / 15.9 inches |
| Width | 196 mm / 7.7 inches |
| Depth | 196 mm / 7.7 inches |
| Weight | 7.6 kg / 16.7 lb |
| Fan Specs | |
| Quantity | 1 (RF-92RC1-B1) |
| Speed | 600 – 1800 ± 200 RPM |
| Airflow | 28.64 CFM |
| Static Pressure | 1.1 mm-H₂O |
| Noise | 23 dBA |
| Fan Connector | 4-pin |
| Model Number | CS-H11BB |
| Compatibility & Clearance | |
| Max GPU Clearance | 324mm |
| Max GPU Thickness | 58mm |
| Memory Height | 46mm |
| Power Supply Specs | |
| Form Factor | SFX (PS-7G1B) |
| Modular | Full |
| Wattage | 750W |
| Compliance Standard | Complies with SFX12V v3.42 ATX12V v2.52 & EPS12V v2.92 |
| Energy Efficiency | 80 Plus Gold |
| Fan | 92mm FDB Silent Fan |
| MTBF | 100,000 hours at 25°C. excluding the DC Fan |
| Protection | OPP, OVP, UVP, OCP, OTP, SCP |
| Front I/O Ports | |
| USB 3.2 Gen 1 Type-A | 2 |
| USB 3.2 Gen 2 Type-C | 1 |
| Headset Audio Jack | 1 |
| Expansion Slots | |
| Standard | 2 |
| Drive Bays | |
| 2.5″ | 2 |
| 3.5″ | – |
| PCIe Extender Cable | |
| Form Factor | X16 |
| Compatibility | PCIe 4.0 Compatible |
| Cable Length | 330 ± 5 mm |
| Compatible Socket & CPU | |
| Intel | Socket LGA 1700, 1200/115X |
| AMD | AMD Socket AM4 |
| Radiator | |
| Dimensions | 139 x 174 x 28 mm |
| Material | Aluminum |
| Pump | |
| Dimensions (D x H) | 65 x 26 mm |
| Motor Speed | 4200 ± 10%RPM |
| Power | 12V DC, 0.35A |
| Fan Controller | |
| Channel | 2 |
| Controller Method | PWM |
| Input | 12V DC |
| Output | 12V DC |
| Fan Specs | |
| Quantity | 1 (Aer P140mm PWM fan) |
| Speed | 500 – 1,800 ± 300RPM |
| Airflow | 27.27 – 98.17 CFM |
| Static Pressure | 0.21 – 2.71 mm-H₂O |
| Noise | 21 – 38 dBA |
| Fan Connector | 4-pin |
| Warranty | 3 Years on case, riser card, and AIO 10 Years on PSU |
| Note | *** Features, Price, Specifications are subject to change without notice. |
- SERIESH1 SERIES
- TYPEMINI TOWER
- 2.5″ BAYS2
- EXPANSION SLOTS2
- COLORMATTE BLACK
- SIDE PANELTRANSPARENT
- NOTE****** Features, Price, Specifications are subject to change without notice.
