Essentials
Product Collection,12th Generation Intel® Core™ i3 Processors
Code Name,Products formerly Alder Lake
Vertical Segment,Desktop
Processor Number,i3-12100
Marketing Status,Launched
Launch Date,Q1’22
Lithography,Intel 7
Use Conditions,PC/Client/Tablet
CPU Specifications
Total Cores,4
# of Performance-cores,4
# of Efficient-cores,0
Total Threads,8
Max Turbo Frequency,4.30 GHz
Performance-core Max Turbo Frequency,4.30 GHz
Performance-core Base Frequency,3.30 GHz
Cache,12 MB Intel® Smart Cache
Total L2 Cache,5 MB
Processor Base Power,60 W
Maximum Turbo Power,89 W
Supplemental Information
Embedded Options Available,Yes
Datasheet,View now
Memory Specifications
Max Memory Size (dependent on memory type),128 GB
Memory Types,Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels,2
Max Memory Bandwidth,76.8 GB/s
Processor Graphics
Processor Graphics,Intel® UHD Graphics 730
Graphics Base Frequency,300 MHz
Graphics Max Dynamic Frequency,1.40 GHz
Graphics Output,eDP 1.4b | DP 1.4a | HDMI 2.1
Execution Units,24
Max Resolution (HDMI),4096 x 2160 @ 60Hz
Max Resolution (DP),7680 x 4320 @ 60Hz
Max Resolution (eDP – Integrated Flat Panel),5120 x 3200 @ 120Hz
DirectX* Support,12
OpenGL* Support,4.5
OpenCL* Support,3.0
Multi-Format Codec Engines,1
Intel® Quick Sync Video,Yes
Intel® Clear Video HD Technology,Yes
# of Displays Supported ,4
Device ID,0x4692
Expansion Options
Direct Media Interface (DMI) Revision,4.0
Max # of DMI Lanes,8
Scalability,1S Only
PCI Express Revision,5.0 and 4.0
PCI Express Configurations ,Up to 1×16+4 | 2×8+4
Max # of PCI Express Lanes,20
Package Specifications
Sockets Supported,FCLGA1700
Max CPU Configuration,1
Thermal Solution Specification,PCG 2020C
TJUNCTION,100°C
Package Size,45.0 mm x 37.5 mm
Advanced Technologies
Intel® Gaussian & Neural Accelerator,3.0
Intel® Thread Director,No
Intel® Deep Learning Boost (Intel® DL Boost),Yes
Intel® Optane™ Memory Supported ,Yes
Intel® Speed Shift Technology,Yes
Intel® Turbo Boost Max Technology 3.0 ,No
Intel® Turbo Boost Technology ,2.0
Intel® Hyper-Threading Technology ,Yes
Intel® 64 ,Yes
Instruction Set,64-bit
Instruction Set Extensions,Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2
Idle States,Yes
Enhanced Intel SpeedStep® Technology,Yes
Thermal Monitoring Technologies,Yes
Intel® Volume Management Device (VMD),Yes
Security & Reliability
Intel® Threat Detection Technology (TDT),Yes
Intel® Standard Manageability (ISM) ,Yes
Intel® Control-Flow Enforcement Technology,Yes
Intel® AES New Instructions,Yes
Secure Key,Yes
Intel® OS Guard,Yes
Execute Disable Bit ,Yes
Intel® Boot Guard,Yes
Mode-based Execute Control (MBEC),Yes
Intel® Virtualization Technology (VT-x) ,Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ,Yes
Intel® VT-x with Extended Page Tables (EPT) ,Yes
